- Operation: two stages
WORKING DIAGRAM
TECHNICAL DATA
| Minimum power output (kW) | 1300 |
| Maximum power output (kW) | 3900 |
| Fan motor (kW) | 9 |
| Protection level | IP42 |
OTHER AVAILABLE CONFIGURATIONS
- Continuous ventilation;
- High temperature;
- High viscosity suitable for 118 cSt (15°E) at 80°C
OVERALL DIMENSIONS
| A | B | C | D | D1 | E | F | G | G1 | H1 | I | L | M |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1205 | 603 | 602 | 350 | 600 | 925 | 320 | 470 | 430 | 746 | 400 | 400 | M16 |
